Bare Shaft & Hydraulically Driven Flexible Impeller Pump
Max. Flow:
43.8m³/hr
Max. Head:
32m
Max. Temp:
100°C
Material:
Metal
All-In-One Flexible Impeller Pump
Our All-In-One Flexible Impeller Pump is a solution built on the exceptional features and functionality of our VA & INV Flexible Impeller Pump. Designed as a comprehensive ready-to-use system, the All-In-One Flexible Impeller Pump optimises fluid transfer operations in cellars and distilleries, covering critical applications such as Free Transfer and Pump-Over. This intelligent pump, offering a seamless and efficient solution, is equipped with 7″ multi-function touch control panels, providing real-time transfer data, enabling volume programming for transfers and facilitating the recording of actual operations for traceability.
Typical applications for our All-In-One Flexible Impeller Pump:
- Free Transfer
- Batch Filling
- Barrel Filling
- Pump-Over
Features & Benefits
- Gearbox driven flexible vane pump with inverter for variable speed control
- Trolley mounted for portability
- Pulsation-free pumping action for the transfer of shear-sensitive liquids
- IP55 rated touch screen control panel for programming transfer and reviewing past transfer operation data
- Remote operation can be carried out using the radio control
- Data can be exported from the control panel onto a USB for analysis on a computer
- High precision food-grade flow meter
- Diagnostic feature to alert of dry run stop, inverter error or auxiliary device issues
- Solids passage capability – 15mm – 25mm
- Self-priming up to 6m without the requirement of a non-return valve
- Pumps can run in both directions via a reversing switch mounted on the panel
- Pump head can be rotated and installed in a range of positions
- Wide range of connection types available including DIN, BSP Male & Female, Triclover, SMS, RJT, Friederich, Garolla and Macron
- Stainless Steel AISI 304 Pipe Fittings for easy integration of the pump into existing applications are available
- Pump heads are SS304 as standard. SS 316 available on request
- Dry run protection on pump body to prevent damage
Specifications
| Materials | Stainless Steel AISI 316L |
| Max Capacity | 43.8m³/hr |
| Max Pressure | 18m |
| Self Priming | No |
| Max Temperature | 100ºC |
