Butterfly Valve
Max. Flow:
N/A
Max. Head:
100m
Max. Temp:
135°C
Material:
Metal
Butterfly Mixproof Valve
Our Butterfly Mixproof Valve is an advanced solution designed for the separation or mixing of 2 applications, with an added leakage chamber for enhanced performance. Also known as a Leakage or Block & Bleed Butterfly Valve, this valve combines the benefits of a standard Butterfly Valve with the innovative mixproof technology. Its operation is driven by the use of 2 discs and 2 seals, ensuring effective isolation of the 2 applications when the valve is closed and seamless mixing when the valve is open.
Typical applications for our Butterfly Mixproof Valve:
- CIP Systems
- CIP return valve in a valve matrix
- Water Management
Features & Benefits
- 3A & FDA certified to ensure compliance with strict sanitary standards
- Available with multiple end-connections
- Available in both manual and actuated options for flexibility in valve control and operation
Specifications
| Sealing Materials | EPDM, HNBR, FPM, VMQ, PTFE |
| Size | Dn25 – DN100, 1″ – 4″ |
| Max Line Pressure | 100m |
| Supply Pressure for Air Actuator | 60m |
| Sterilisation Temperature | 135°C |
