Industrial Rubber Lobe Pump
Max. Flow:
300m³/hr
Max. Head:
50m
Max. Temp:
40°C
Material:
Metal
EHEDG Lobe Pump
Our EHEDG Lobe Pump is a versatile sanitary solution designed for the Food, Cosmetic and Pharmaceutical industries. EHEDG-certified, this pump ensures optimal hygiene and increased corrosion resistance with its Cast Stainless Steel AISI 316L construction. With 11 pump sizes, various sealing options and elastomer materials, it stands out as one of the most versatile Lobe Pumps on the market today. Capacities up to 110m³/hr, discharge pressures up to 15 Bar and ATEX availability for hazardous environments make this pump suitable for a range of applications.
Typical applications for our EHEDG Lobe Pump:Â
- Dairy
- Bakery products
- Beverages
- Cosmetics
- Meat products
- Egg products
- Viscous products
- Starch products
Features & Benefits
- ATEX available
- Speed range up to 1500 rpm
- Fully EHEDG Compliant
- Wide Variety Interchangeable Sealing Options – Modular design
- Complete Front Pull-Out of Mechanical Seal & Lobes
- High-Efficiency B-Wing or Low Pulsation Quattro Lobe Designs available
- Flat Front Cover to ensure more efficient cleaning
- Can be mounted Horizontally or Vertically in pipework
- When mounted vertically the pump is self-draining
- Accurate flow control from 0.04 – 2.5 l/rev
- Discharge Pressures up to 15 Bar
- Variable fluid temperatures up to 140ºC
- CIP/SIP friendly – minimal dead spaces
- Suitable for Shear Sensitive Fluids
- Suitable for pumping fragile solids
- Wide variety of connection types
- Optional Heating & Cooling Jackets
- Optional Air or Spring Loaded Integral Safety Valves
Specifications
| Materials | Cast Stainless Steel AISI 316L |
| Max Capacity | 110m³/hr |
| Max Pressure | 150m |
| Self Priming | Yes |
| Max Solids Passage | 60mm |
| Max Temperature | 140ºC |
| Viscosity | 1,000,000 cPs |
