Eco Friendly Plastic Diaphragm Pump
Max. Flow:
34m³/hr
Max. Head:
80m
Max. Temp:
100°C
Material:
Plastic/Metal
Electric Diaphragm Pump
Our Electric Diaphragm Pump is an environmentally friendly alternative to our Air Operated Diaphragm Pump. Available in HDPE/PTFE, Metal and Sanitary variants, this Electric Diaphragm Pump uses a gear motor, employing one diaphragm for suction and the other for transmitting air pressure to the fluid. For increased performance, our Electric Diaphragm Pump delivers capacities up to 220 l/min and pressures up to 4 Bar.
Typical industries for our Electric Diaphragm Pump:Â
- Chemical
- Surface Treatment
- Water Treatment
- Paint & Print
- Pulp & Paper
- Hygienic
- Mechanical
Features & Benefits
- Can be run dry with no damage
- Has the option to self-prime from a dry suction pipe
- No hydraulic fluid is required, meaning clean and easy maintenance with no risk of leakage
- Low spares cost and few components
Specifications
| Materials | HDPE, Metal & Sanitary |
| Max Capacity | 220 l/min |
| Max Pressure | 40m |
| Self Priming | Yes |
| Max Solids Size | 10mm |
| Max Temperature | 110ºC |
| Viscosity | 20,000 cPs |
