In-Line Centrifugal Pump
Our In-Line Centrifugal Pump is a versatile solution tailored for applications where operational parameters, such as flow rates and pressure requirements, are known and fixed. This pump allows for space-saving installation and minimal pipework as it has been designed to be installed in a pipeline in order to pump fluid in the same direction as the pump. To meet specific operational needs, this pump is available in diverse materials including Stainless Steel, Plastic and Aluminium. This material versatility makes it well-suited for handling a range of liquids, including clean and slightly contaminated low viscosity liquids without solids and fibrous particles, chemicals and other industrial fluids.
Typical applications for our In-Line Centrifugal Pump:
- HVAC
- Water supply and circulation systems
- Industrial processes
- Chemical dosing
Features & Benefits
- Horizontal, radially split volute casing, single stage, end suction
- ATEX available
- Pump and motor shafts are separated by either rigid coupling or through slide fit shaft resulting in axial and radial forces being absorbed by the electric motor bearings
- Flanges conform to EN1092-2/PN 10 or PN16. (EN 1092-1/PN 10 or PN 16 for steel/stainless-steel casing). ANSI/ASME flanges are also available
- Dynamically and statically balanced impellers, in accordance with ISO 1940 Grade 6.3
- Impellers utilise balancing holes to balance axial thrust
- Vertical mounting allows for minimal footprint for small installation areas
Specifications
| Materials | Stainless Steel AISI 316L, Plastic, Aluminium |
| Max Capacity | 200m³/hr |
| Max Pressure | 100m |
| Self Priming | No |
| Max Temperature | 140ºC |
